3-48 2G0947 - 31JAN08
Adjustments and Replacements
FILM FEED AY
Prerequisites: Remove:
• “BACK PANEL”
• “PICKUP AY - UPPER”
To Remove:
IMPORTANT:
Verify that the OPTICS AY ALIGNMENT PINS are in the down position.
ALIGNMENT PIN
(down position)
