3-36 2G0947 - 31JAN08
Adjustments and Replacements
To remove the GASKET on the INLET SHIELD:
1. Remove:
• “PROCESSOR COVER”
• 2 SCREWS
• INLET SHIELD
2. Pull off the old GASKET.
To Install: 1. Use ALCOHOL WIPES to clean the adhesive from the GASKETS.
2. Remove the paper backing from the new GASKETS.
3. Set the GASKETS in place.
4. Press down firmly all around the GASKETS.
5. Reverse the steps in the removal procedure.
2 SCREWS
INLET SHIELD
GASKET
