Illustrated Parts List
Figure 6-17: PROCESSOR FRAME AY (1 of 4) - Parts List
Item Part No. Description Qty Notes
1 SP7F2484 PULLEY - 16 groove 1
2 SP8F3170 MOTOR - turnaround roller drive 1 M9
3 SP8F4702 RETAINER - switch 2
4 SP26-1011-6202-7 SWITCH - interlock, side panel 2
5 SP7E7511 BEARING - sleeve 3
6 SP5F8101 SCREW - Torx, M4 0.7x25 4
7 SP8F2719 HUB - drive 2
8 SP5F7058 E-RING - 9-12 mm 3
9 SP8F4693 WHEEL - drive, turnaround 1
10 SP8F4692 COVER - wheel, drive 1
11 SP8F2686 ROLLER - crowned 9
12 SP5F4586 E-RING - 6-8 mm 24
13 SP5F7631 BEARING - ball 2
To Next Page
