KUHN MAXIMA 2 - Page 179

Optional equipment
Precision Seed Drills
MAXIMA 2
177
Hopper of 1350 L (356 US gal)
- Raise protection cover (1).
Hopper of 2x280 L (2x74 US gal)
- Open hood (3).
Hopper of 1350 L (2x74 US gal)
Raise protection cover (1).
Hopper of 2x280 L (2x74 US gal)
- Close hood (3).
If the machine is fitted with an access platform:
- Raise access platform.
Emptying the hopper
- Place a container (1) underneath the hatch that does
not supply a metering unit.
- Open hatch.
Make sure that sieve (2) is well installed.
Before filling, check that there is no foreign
matter in the hopper.
The machine can be fitted with a loading screw
for easier hopper filling.
- Loading screw for fertilizer equiped with
2 x 280 L (2 x 74 US gal) hoppers Kit
no. 1677225.
- Loading screw for fertilizer unit fitted
with a 1350 L (356 US gal) hopperKit
no. 1677227.
