KUHN MAXIMA 2 - Page 98

Precision Seed Drills
96
MAXIMA 2
Instructions for work
Adjust gearbox gearwheel and chain position according
to the ratio recommended in the calibration chart.
Example:
Ratio to adjust: D1.
- Position chain on upper level gearwheel D.
- Position chain on lower level gearwheel 1.
Variation of 6 % between each ratio.
