Instructions for work
Precision Seed Drills
MAXIMA 2
97
Adjustment:
- Remove lynch pin (1).
- Open gearbox (2).
- Lower lever (1) until chain tension is loosened.
- Push handle (2) to lock lever (1) in low position.
- Position lever (3) in notch (4) to enable moving the
upper level gearwheels sideways.
- Position chain (5) on the recommended gearwheels.
