Part Names (Connectors/Interior)

1 USB Interface Connector (Option in Europe)

2 Network Interface Connector

3 Option Interface Slot

4 Toner Container (Black)

5 Toner Container (Magenta)

6 Toner Container (Cyan)

7 Toner Container (Yellow)

8 Waste Toner Box
