2
3
3
2
1
Thumb screws
Pins
Figure43.Hot-swapharddiskdrivebackplaneinstallation
Step3.Reinstalltheharddiskdrivesandfillerpanels(see“Installingahot-swapharddiskdrive”on
page91
).
Step4.Reconnectallcablesthatyouremovedfromtheharddiskdrivebackplane(see“Internalcable
routingandconnectors”onpage144
).
Step5.Reinstallthefancagecover(see“Installingthefancagecover”onpage83).
1.Installtheserverintotherackenclosureandpushtheserverintotherackuntilitclicksintoplace.
2.Reconnectthepowercordsandanycablesthatyouremoved.
3.Turnontheperipheraldevicesandtheserver.
Removinganadapter
Usethisinformationtoremoveanadapter.
Readthesafetyinformationin“Safety”onpagevand“Installationguidelines”onpage75.
Ifyouarereplacingaservercomponentorinstallinganoptionaldeviceintheserver,youneedtotake
outthenodeoutfromtherackenclosure,turnofftheserverandperipheraldevices,anddisconnectall
externalcables.
Toremoveanadapter,completethefollowingsteps.
Step1.Removethecomputenode(see“Removingacomputenodefromachassis”onpage77).
Step2.RemovethePCIriser-cardassembly(see“RemovingthePCIriser-cardassembly”onpage117).
Step3.Disconnectthecablesfromtheadapterifany.
Step4.PlacethePCIriser-cardassemblyonaflat,static-protectivesurface.
Step5.Removethescrew.
