OCP adapter
(Intel X520)
Bezel (Intel X520)
OCP connector
Figure55.LANMezzadapterinstallation(IntelX520)
000000
000000
000000
000000
000000
000000
000000
000000
000000
000000
00
00
00
00
00
00
000000
000000
000000
000000
000000
OCP adapter
(RJ-45)
Bezel (RJ 45)
OCP connector
Figure56.LANMezzadapterinstallation(RJ45)
Step5.Reinstallthebezelbytightenthe2screws.
Step6.Reinstallcomputenode(see“Installingacomputenodeinachassis”onpage77).
1.Installtheserverintotherackenclosureandpushtheserverintotherackuntilitclicksintoplace.
2.Reconnectanycablesthatyouremoved.
3.Turnontheperipheraldevicesandtheserver.
Note:IftheserverisconfiguredforRAIDoperationthroughanoptionalRAIDadapter,youmighthave
toreconfigureyourdiskarraysafteryouinstallanadapter.SeetheRAIDdocumentationontheLenovo
RAIDSupportCDforadditionalinformationaboutRAIDoperationandcompleteinstructionsforusing
RAIDManager.
RemovingthePCIriser-cardassembly
UsethisinformationtoremovethePCIriser-cardassembly.
Readthesafetyinformationin“Safety”onpagevand“Installationguidelines”onpage75.
Chapter5.Removingandreplacingservercomponents117
