Lenovo ThinkServer sd350 - Removing an HBA Adapter

PCI riser assembly
Adapter
Expansion-slot filler
Screw
Figure46.Adapterinstallation
Step5.Tightenthescrew.
Step6.Reconnectthecablestotheadapterthatyouremovedearlier.
Step7.ReinstallthePCIriser-cardassembly(see“ReplacingthePCIriser-cardassembly”onpage118).
Attention:Whenyouinstallanadapter,makesurethattheadapteriscorrectlyseatedinthePCI
riser-cardassemblyandthatthePCIriser-cardassemblyissecurelyseatedintheriser-card
connectoronthesystemboardbeforeyouturnontheserver.Anincorrectlyseatedadaptermight
causedamagetothesystemboard,thePCIriser-cardassembly,ortheadapter.
Step8.Reinstallcomputenode(see“Installingacomputenodeinachassis”onpage77).
1.Installtheserverintotherackenclosureandpushtheserverintotherackuntilitclicksintoplace.
2.Reconnectanycablesthatyouremoved.
3.Turnontheperipheraldevicesandtheserver.
Note:IftheserverisconfiguredforRAIDoperationthroughanoptionalRAIDadapter,youmighthave
toreconfigureyourdiskarraysafteryouinstallanadapter.SeetheRAIDdocumentationontheLenovo
RAIDSupportCDforadditionalinformationaboutRAIDoperationandcompleteinstructionsforusing
RAIDManager.
RemovinganHBAadapter
UsethisinformationtoremoveanHBAadapter.
Readthesafetyinformationin“Safety”onpagevand“Installationguidelines”onpage75.
Ifyouarereplacingaservercomponentorinstallinganoptionaldeviceintheserver,youneedtotake
outthenodeoutfromtherackenclosure,turnofftheserverandperipheraldevices,anddisconnectall
externalcables.
ToremoveanHBAadapter,completethefollowingsteps.
