Figure60.SATADOMinstallation
Step3.Reinstallcomputenode(see“Installingacomputenodeinachassis”onpage77).
1.Installtheserverintotherackenclosureandpushtheserverintotherackuntilitclicksintoplace.
2.Reconnectanycablesthatyouremoved.
3.Turnontheperipheraldevicesandtheserver.
RemovingandreplacingFRUs
ThissectionprovidesinformationforremovingandreplacingFRUsintheserver.
FRUsmustbeinstalledonlybytrainedservicetechnicians.
Theillustrationsinthisdocumentmightdifferslightlyfromyourhardware.
Removingthefanboard
Usethisinformationtoremovethefanboardfromtheserver.
Readthesafetyinformationin“Safety”onpagevand“Installationguidelines”onpage75.
Ifyouarereplacingaservercomponentorinstallinganoptionaldeviceintheserver,youneedtoslidethe
serveroutfromtherackenclosure,turnofftheserverandperipheraldevices,anddisconnectthepower
cordsandallexternalcables.
Toremovethefanboard,completethefollowingsteps.
Step1.Removeallthenodes(see“Removingacomputenodefromachassis”onpage77).
Step2.Removethefancagecover(see“Removingthefancagecover”onpage82).
Step3.Removethesystemfan(see“Removingasystemfan”onpage88).
Step4.Removethefancage(see“Removingthefancage”onpage105).
Chapter5.Removingandreplacingservercomponents121
