Readthesafetyinformationin“Safety”onpagevand“Installationguidelines”onpage75.
Ifyouarereplacingaservercomponentorinstallinganoptionaldeviceintheserver,youneedtotake
outthenodeoutfromtherackenclosure,turnofftheserverandperipheraldevices,anddisconnectall
externalcables.
ToremoveaLANMezzadapter,completethefollowingsteps.
Step1.Disconnecttheexternalcablesfromtheadapter.
Step2.Removethecomputenode(see“Removingacomputenodefromachassis”onpage77).
Step3.RemovethePCIriser-cardassembly(see“RemovingthePCIriser-cardassembly”onpage117).
Step4.Removethe2screwsofthefrontbezelandremovethebezel.
Step5.Removethe4screwsfromtheadapter.
Step6.Carefullygrasptheadapterbyitstopedgeoruppercorners,andpulltheadapteroutofthe
computenode.
000000
000000
000000
000000
000000
000000
000000
000000
000000
000000
00
00
00
00
00
00
000000
000000
000000
000000
000000
OCP adapter
(Intel X520)
Bezel (Intel X520)
Figure52.LANMezzadapterremoval(IntelX520)
000000
000000
000000
000000
000000
000000
000000
000000
000000
000000
00
00
00
00
00
00
000000
000000
000000
000000
000000
OCP adapter
(RJ-45)
Bezel (RJ 45)
Figure53.LANMezzadapterremoval(RJ45)
Ifyouareinstructedtoreturntheservercomponentoroptionaldevice,followallpackaginginstructions,
anduseanypackagingmaterialsforshippingthataresuppliedtoyou.
