Lenovo ThinkSystem SR665 V3 - Management NIC Adapter

M.2 x4 SATA/NVMe 2-bay backplane
Figure 272. SATA/NVMe M.2 cable routing Figure 273. RAID cable routing
From To From To
1 Power connector on the
M.2 drive backplane
1 M.2 power connector on
the system board assembly
1 Power connector on the
M.2 drive backplane
1 M.2 power connector on
the system board assembly
2 Signal connector on the
M.2 drive backplane
2 Onboard: PCIe 10, 11 2 Signal connector on the
M.2 drive backplane
2 8i adapter: C0
Management NIC adapter
Use the section to understand the cable routing for the ThinkSystem V3 Management NIC Adapter Kit
(management NIC adapter).
