Lenovo ThinkSystem SR665 V3 - Backplanes

From To
1 Backplane 5: NVMe 0-1, 2-3
1 Retimer card: C0, C1
2 Backplane 6: NVMe 0-1, 2-3
2 Retimer card: C0, C1
3
• Backplane 5: PWR
• Backplane 6: PWR
3
• Onboard: rear backplane power
• Onboard: rear backplane sideband
• Riser 1: PWR
One 8 x AnyBay and two 8 x NVMe backplanes
This section provides cable routing information for the server model with one 8 x 2.5-inch AnyBay and two 8
x 2.5-inch NVMe front backplanes.
To connect power cables for the front backplane(s), refer to
“Backplanes: server models with 2.5-inch front
drive bays” on page 312
.
To connect signal cables for the front backplane(s), refer to the following cable routing scenarios depending
on your server configuration.
•
“8i RAID/HBA adapter + One retimer card” on page 408
• “8i RAID/HBA adapter + Three retimer cards” on page 411
8i RAID/HBA adapter + One retimer card
The following shows the cable connection for the front (8 x 2.5-inch AnyBay + 16 x 2.5-inch NVMe)
configuration with one 8i RAID/HBA adapter and one retimer card.
Connections between connectors:
1 ↔ 1 , 2 ↔ 2 , 3 ↔ 3 , ... n ↔ n
