RAID flash power module
This section provides cable routing information for the RAID flash power module (also called supercap).
Table 27. Location of RAID flash power modules
Figure 276. On the chassis
Figure 277. On standard air baffle
Figure 278. On GPU air baffle
Figure 279. On the 2.5-inch middle drive cage
An extension cable is provided for each RAID flash power module for cable connection. Connect the cable
from the RAID flash power module to the corresponding RAID adapter as shown.
