C
HAPTER
4
| Configuring the Switch
Configuring Security
– 102 –
matches this entry when ARP/RARP protocol address space setting
is equal to IP (0x800)
■
IPv4 frames (based on destination MAC address, protocol type, TTL,
IP fragment, IP option flag, source/destination IP, VLAN ID, VLAN
priority)
PARAMETERS
These parameters are displayed:
ACCESS CONTROL LIST CONFIGURATION
◆ Ingress Port - The ingress port of the ACE:
■
All - The ACE will match all ingress ports.
■
Port - The ACE will match a specific ingress port.
◆ Policy / Bitmask - The policy number and bitmask of the ACE.
◆ Frame Type - The type of frame to match.
◆ Action - Shows whether a frame is permitted or denied when it
matches an ACL rule.
◆ Rate Limiter - Shows if rate limiting will be enabled or disabled when
matching frames are found.
◆ Port Redirect - Port to which frames matching the ACE are redirected.
◆ Counter - Shows he number of frames which have matched any of the
rules defined for this ACL.
The following buttons are used to edit or move the ACL entry (ACE):
ACE CONFIGURATION
Ingress Port and Frame Type
◆ Ingress Port - Any port, port identifier, or policy. (Options: Any port,
Port 1-10, Policy 1-8; Default: Any)
Table 8: QCE Modification Buttons
Button Description
Inserts a new ACE before the current row.
Edits the ACE.
Moves the ACE up the list.
Moves the ACE down the list.
Deletes the ACE.
The lowest plus sign adds a new entry at the bottom of the list.
