C HAPTER 5 | Monitoring the Switch
Displaying MVR Information
– 256 –
WEB INTERFACE
To display information on spanning port statistics, click Monitor, Spanning
Tree, Port S tatistics.
Figure 127: Spanning Tree Port Statistics
DISPLAYING MVR INFORMATION
Use the monitor pages for MVR to display information on MVR statistics and
active multicast groups.
DISPLAYING MVR
STATISTICS
Use the MVR Statistics page to display statistics for IGMP protocol
messages used by MVR.
PATH
Monitor, MVR, Statistics
PARAMETERS
These parameters are displayed:
◆ VLAN ID – Identifier of the VLAN that serves as the channel for
streaming multicast services using MVR.
◆ IGMP/MLD Queries Received – Number of received queries for IGMP
and MLD, respectively.
◆ IGMP/MLD Queries Transmitted – Number of transmitted queries
for IGMP and MLD, respectively.
◆ IGMPv1 Joins Received – Number of received IGMPv1 Joins.
◆ IGMPv2/MLDv1 Reports Received – Number of received IGMPv2
Joins and MLDv1 Reports, respectively.
◆ IGMPv3/MLDv2 Reports Received – Number of received IGMPv1
Joins and MLDv2 Reports, respectively.
◆ IGMPv2/MLDv1 Leaves Received – Number of received IGMPv2
Leaves and MLDv1 Dones, respectively.
