L-VIS User Manual 39 LOYTEC
Version 6.2 LOYTEC electronics GmbH
4 Mechanical Installation
4.1 Dimensions and Mounting
For information about unit installation, please refer to the installation sheet that came with
your unit. This document is also available for download from the LOYTEC website.
4.2 Theft Protection
To protect devices of type LVIS-3E100 and LVIS-ME200, they can be fixed to the wall
mount frame with the supplied chain as shown in Figure 1.
Figure 1: Connecting L-VIS to the wall mount frame.
