5 Electrical Installation
5.1 Connection diagram
For information about unit installation, please refer to the installation sheet that came with
your unit. This document is also available for download from the LOYTEC website.
5.2 Electrical Characteristics LVIS-3E100/ME200
The electrical characteristics of the LVIS-3E100 and LVIS-ME200 devices are shown in
Table 2.
Characteristics
Value
Operating voltage
24 VDC or 24 VAC ± 10%
Power consumption
4 W, idle: 2W (backlight off)
In-rush current
Up to 1000 mA @ 24 VAC
Operating temperature (ambient)
10°C to +40°C
Storage temperature
-10°C to +50°C
Humidity (non-condensing) operating
10 to 90 % RH @ 50°C
Humidity (non-condensing) storage
10 to 90 % RH @ 50°C
Switch input
Floating contact
Ethernet connection
100Base-T
CEA-709
FT-10/LPT-10
BACnet/MSTP
RS485, 1 Unit Load
Enclosure
Stainless steel, anodized aluminum front panel E6C0
Electrical Appliance Protection Class
(IEC 61140)
Class I
IP Code (IEC 60529)
Front: IP54 / Back: IP10
LCD display
320x240 pixels, 256 colors
LCD backlight
LED backlight, 40 000 hours / auto off
Installation
Wall mount
Table 2: Electrical characteristics 3E100/ME200
5.3 Electrical Characteristics LVIS-3E11x/ME21x
The electrical characteristics of the LVIS-3E11x and LVIS-ME21x devices are shown in
Table 3.
