LOYTEC L-VIS User Manual

L-VIS User Manual 41 LOYTEC
Version 6.2 LOYTEC electronics GmbH
Characteristics
Value
Operating voltage
24 VDC ± 10%, or 90-265 VAC
Power consumption
12 inch: 14W, 15 inch: 17W, idle: 3.5W
In-rush current
Up to 3.7A @ 24 VAC, max. 40ms
Operating temperature (ambient)
10°C to +40°C
Storage temperature
-10°C to +50°C
Humidity (non-condensing) operating
10 to 90 % RH @ 50°C
Humidity (non-condensing) storage
10 to 90 % RH @ 50°C
Switch input
Floating contact
Ethernet connection
2x 100Base-T, integrated Ethernet switch for daisy-
chaining up to 20 devices
CEA-709
FT-10/LPT-10
BACnet/MSTP
RS485, 1 Unit Load
Enclosure
Stainless steel, anodized aluminum front panel E6C0
Electrical Appliance Protection Class
(IEC 61140)
Class I
IP Code (IEC 60529)
Front: IP54 / Back: IP10
LCD display
12 inch: 800x600 pixel, 15 inch: 1024x768 pixel,
65k color TFT
LCD backlight
LED backlight, 50 000 hours / auto off
Installation
Wall mount
Table 3: Electrical characteristics 3E11x/ME21x
5.4 Electrical Characteristics LVIS-3MEx
The electrical characteristics of the LVIS-3MEx devices are shown in Table 4.
