LOYTEC L-VIS User Manual

L-VIS User Manual 42 LOYTEC
Version 6.2 LOYTEC electronics GmbH
Characteristics
Value
Operating voltage
24 VDC ± 10%, or 90-265 VAC (except 7” models)
Power consumption
See Table 5
Operating temperature (ambient)
10°C to +40°C
Storage temperature
-10°C to +50°C
Humidity (non-condensing) operating
10 to 90 % RH @ 50°C
Humidity (non-condensing) storage
10 to 90 % RH @ 50°C
Switch input
Floating contact
Ethernet connection
2x 100Base-T, integrated Ethernet switch for daisy-
chaining up to 20 devices
CEA-709
FT-10/LPT-10
BACnet/MSTP
RS485, 1 Unit Load
Enclosure
Stainless steel
Front (-A models)
Anodized aluminum front panel E6C0
Front (-G models)
Glass
Electrical Appliance Protection Class
(IEC 61140)
Class I
IP Code (IEC 60529)
Front: IP54 / Back: IP10
LCD display
See Table 1
LCD backlight
LED backlight, 50 000 hours / auto off
Installation
Wall mount
Table 4: Electrical characteristics 3E11x/ME21x
The following table summarizes power consumption for the LVIS-3ME family.
LVIS-3ME7
Supply
Power
Current
Peak
Active
24 VDC
5.0 W
250 mA
310 mA
Standby
24 VDC
2.5 W
160 mA
220 mA
LVIS-3ME12
Supply
Power
Current
Peak
Active
24 VDC
9.3 W
410 mA
490 mA
110 VAC
11.3 W
210 mA
880 mA
230 VAC
13.3 W
140 mA
720 mA
Standby
24 VDC
2.9 W
120 mA
240 mA
110 VAC
5.4 W
90 mA
550 mA
230 VAC
5.9 W
70 mA
370 mA
LVIS-3ME15
Supply
Power
Current
Peak
Active
24 VDC
9.4 W
440 mA
510 mA
110 VAC
11.3 W
210 mA
860 mA
230 VAC
13.1 W
150 mA
670 mA
Standby
24 VDC
4.2 W
220 mA
280 mA
110 VAC
7.0 W
140 mA
560 mA
230 VAC
8.2 W
80 mA
460 mA
Table 5: Power consumption LVIS-3MEx
