10 Appendix
10.1 Tools and consumables
10.1.1 Tools
Any tool for the circuit board plotter can be ordered individually:
Tab. 16: Tools
Tool specification
Length
(mm)
Ø
(mm)
Order
code
End Mill RF, special tool, cylindrical, 1/8“
36
0,15
115 832
End Mill RF, special tool, cylindrical, 1/8“
36
0,25
115 833
End Mill RF, special tool, cylindrical, 1/8“
36
0,40
115 834
Universal Cutter, conical, 1/8“
36
0,2/0,5
115 835
Micro Cutter, Fine Line, conical, 1/8“
36
0,1/0,15
115 836
End Mill long, cylindrical, PCB/aluminium 1/8“
38
1,00
115 837
End Mill long, cylindrical, PCB/aluminium 1/8“
38
2,00
129 102
End Mill, cylindrical, PCB/aluminium, 1/8“
36
0,80
115 839
End Mill, cylindrical, PCB/aluminium, 1/8“
36
1,00
115 840
End Mill, cylindrical, PCB/aluminium, 1/8“
36
2,00
129 100
End Mill, cylindrical, PCB/aluminium, 1/8“
36
3,00
129 101
Contour Router, special tool, cylindrical, 1/8“
38
1,00
115 844
Contour Router, special tool, cylindrical, 1/8“
38
2,00
129 099
Spiral Drill, cylindrical, 1/8“
38
0,20
115 846
Spiral Drill, cylindrical, 1/8“
38
0,30
115 847
Spiral Drill, cylindrical, 1/8“
38
0,40
115 848
Spiral Drill, cylindrical, 1/8“
38
0,50
115 849
Spiral Drill, cylindrical, 1/8“
38
0,60
115 850
Spiral Drill, cylindrical, 1/8“
38
0,70
115 851
Spiral Drill, cylindrical, 1/8“
38
0,80
115 852
Spiral Drill, cylindrical, 1/8“
38
0,85
115 853
Spiral Drill, cylindrical, 1/8“
38
0,90
115 854
Spiral Drill, cylindrical, 1/8“
38
1,00
115 855
Spiral Drill, cylindrical, 1/8“
38
1,10
115 856
Spiral Drill, cylindrical, 1/8“
38
1,20
115 857
Spiral Drill, cylindrical h, 1/8“
38
1,30
115 858
Spiral Drill, cylindrical, 1/8“
38
1,40
115 859
