LPKF ProtoMat S - Multilayer Material; Dispense Material

Appendix
ProtoMat S
104 HB V2.0/Dez-11 © 2011 LPKF AG
10
10.1.2.2 Multilayer material
Tab. 20:
Multilayer
material
Material
Dimensions
(mm)
Copper
(µm)
Quan-
tity
Order code
Thin laminate 104 ML
with protective foil for
galvanic
229 x 305 x 0,2
-/5
1
119 571
Prepeg Type 2125
275 x 200 x 0,1
/
2
119 572
Base material FR4
229 x 305 x 1,0
18/18
1
119 574
Base material 104 ML
229 x 305 x 0,36
18/18
1
119 575
Thin laminate 104 ML
without protective foil for
ProConduct
229 x 305 x 0,2
-/18
1
119 818
Pressing plate with
reference holes
229 x 205 x 1,6
/
1
120 345
Press cushion with
reference holes
229 x 305 x 1,7
/
1
120 999
10.1.2.3 Dispense material
Tab. 21: Dispense
material
Material
Quantity
Order
code
Dispense needle
1
129 130
SolderPaste with cartridge
1
129 096
