3 Functional description
In the following chapter describes the function of the circuit board plotter in
detail.
3.1 Function
The circuit board plotter ProtoMat S is employed for processing of electrical
printed circuit boards. Printed circuit boards can consist of several layers
(multilayer) and may have up to six layers. In addition the ProtoMat S can be
employed for processing of signs or housing components (front plate).
The circuit board plotter can be used for the following machining processes:
●
Milling and drilling of single or double sided base material
●
Milling and drilling of multilayer materials
●
Milling of SMD soldering paste stencils
●
Milling of solder resist masks
●
Engraving of labels or housing plates
●
Milling of 3D objects
●
Milling of cut-outs and outlines
●
Perforating of planar materials
●
Dispensing
