1.3 Scope of delivery
The scope of delivery for the ProtoMat S Series includes:
Tab. 1: Scope of
delivery
Quantity
Description
1
ProtoMat S series with sound proof housing
1
Power cable with safety plug (230 V AC), length 1,5 m
1
Power cable with US plug (115 V AC), length 1,5 m
1
USB connection cable, 3 m
1
Drill underlay material with the dimensions 229 x 305 mm (9 x 12“)
1
Base material FR4 with the dimensions 229 x 305 mm (9 x 12“)
1
Tool set with:
2
Reference hole stripes
5
Reference hole pivots (3 x 8 mm)
1
Force fitting tool for reference hole pivots
1
Fuse 10 A (T10L 250 V)
2
Reference hole drill, spiral drill 2.95 mm
1
Fixing tape (to be dissolved residual-free)
1
Maintenance and service set
1
Set of CD-ROMs consisting of
1
Software CircuitPro
1
Start up ProtoMat
1
Set of operation manuals consisting of
1
Operating manual CircuitPro
1
Operating manual ProtoMat S
1.3.1 Accessories
The following components can be delivered as accessories:
Tab. 2:
Accessories
Quantity
Description
1
Tool set 1/8“
1
HF tool set 1/8“
1
Dust extraction unit with auto switch feature
1
Vacuum table to fix work pieces
1
Vision System for detection of fiducials (option for ProtoMat S43)
1
Measuring microscope to check milling tracks and drill holes
1
Status Light
