4 Transport and storage
The following chapter gives some information concerning transport and storage
of the circuit board plotter.
4.1 Transport
Risk of injury due to heavy load!
The machine is heavy and bulky and cannot be transported or
lifted by one person!
Lift and transport the machine always with two persons.
For transports over large distances the circuit board plotter has to be stored in
the delivered covering box. The covering box has to be placed and fixed on an
euro pallet.
For transports over short distances the circuit board plotter can be take out of
the covering box to be carried by two persons to the working desk.
4.1.1 Transport lock
Fix the mill/drill head with a transport protection band and place a foam mat
under the mill/drill head.
4.2 Storage
The circuit board plotter has to be stored in its covering box in a
cool and dry environment.
During longer down or storage times, transport locks have to be installed and
the circuit board plotter has to be stored in its covering box. Store the circuit
board plotter in a cool and dry location. Use a protective cover to protect it from
dust and humidity.
