Functional description
ProtoMat S
30 HB V2.0/Dez-11 © 2011 LPKF AG
3
3.2.2 Working area
3.2.2.1 Worktable ProtoMat S43
Fig. 9: Worktable
ProtoMat S43
/1/ Worktable
/2/ Power switch
/3/ Fixing pin
/4/ Mill/Drill head
2
1
3
4
