9 Storage
This chapter describes the storage of the circuit board plotter.
9.1 Shutdown
Before the machine can be stored set the circuit board plotter out of operation.
■ Disassembly of the circuit board plotter
1. Switch off the circuit board plotter and the dust extraction.
2. Unplug the mains cable from the electrical safety socket.
3. Remove the tube from the dust extraction.
4. Remove the connection cable from the dust extraction.
5. Remove the USB cable from the PC.
6. Open the hood and remove the mains cable.
7. Install the transport locks.
8. Place all the connection cables on the working table and close the hood.
♦ Now the circuit board plotter is disassembled.
The PC and the dust extraction have to be disassembled
accordingly. The systems can be used for other machines or they
can be stored as well. The appropriate information concerning
disassembly and storage can be found in the respective operation
manuals.
