Functional description
ProtoMat S
34 HB V2.0/Dez-11 © 2011 LPKF AG
3
3.2.3.2 Mill/drill head ProtoMat S63/103
Fig. 15: Mill/drill
head ProtoMat
S63/S103
/1/ Status LED
/2/ Tool holder
/3/ Dispenser
/4/ Camera
Tab. 2: LED
signalling
ProtoMat S63/
S103
LED
Signal
ON
The circuit board plotter is ready for operation.
Flashing
The flashing LED indicates the movement of the mill/drill head or a
machine failure.
1
2
4
3
