8 Maintenance/servicing
This chapter lists the most important maintenance and servicing activities.
8.1 Regular maintenance
Regular maintenance of the circuit board plotter includes a visual inspection
before any start of operation and regular careful cleaning.
■ Visual inspection
1. Check the mains cable of the circuit board plotter, the USB cable to the
PC, the connection cable and the tube to the dust extraction.
➨ Replace damaged cables or tubes at once.
2. Check the soundproof hood for visible damages.
3. Open the hood and check the mill/drill head and the working table for
visible damages.
Contact the LPKF service immediately whenever you find a damaged part
and make sure that the circuit board plotter is not used until the damaged
part is removed.
♦ The visual inspection is successfully terminated and the circuit board plotter
can be set to operation.
■ Cleaning the circuit board plotter
Clean the circuit board plotter with a dry and antistatic cloth and a
paintbrush. To remove heavy soiling use a slightly damp cloth.
1. Disconnect the circuit board plotter from the mains power supply.
2. Clean the soundproof hood using a dry and antistatic cloth.
3. Open the hood and clean the working table with a paintbrush and slightly
damp cloth.
4. Close the hood after cleaning.
5. Connect the circuit board plotter to the mains power supply.
♦ Now the circuit board plotter is cleaned.
