Functional description
ProtoMat S
40 HB V2.0/Dez-11 © 2011 LPKF AG
3
3.4.3 ProtoMat S103
Technical data circuit board plotter type ProtoMat S103:
Tab. 8: Technical
data ProtoMat
S103
Data
Values
Mains power supply
Voltage range from 110 to 240 V AC, 50 - 60 Hz
Power consumption
400/450 W
Weight
Appr. 60 kg
Dimension
670 x 540 x 760 mm (W x H x D)
Permissible ambient temperature
Range from 15 to 25 °C
Permissible atmospheric humidity
Up to 60 %
Workplace noise level
71 dB (A), devoid of noise level dust extraction
Motor mill/drill head
Three phase motor
Range of speeds
Up to 100,000 min
-1
(variable)
Processing speed
150 mm/s
Drilling capacity
150 strokes per minute
Tool change mechanism
Automatically
Number of tools
Up to 15 tool holder positions, software limit
Tool collet base
3.175 mm (1/8“)
Motor X axis
Three phases stepping motor
Motor Y axis
Three phases stepping motor
Motor Z axis
Two phases stepping motor
Milling depth adjustment
Automatically
Working area with work table
305 x 229 x 38 mm (X x Y x Z)
Working area with MKHP plate
305 x 229 x 32 mm (X x Y x Z)
Working area with vacuum table
305 x 229 x 23 mm (X x Y x Z)
Resolution (X/Y)
+/- 0.25 µm (0.01 Mil)
Repeat accuracy
+/- 5 µm (0.2 Mil)
Exactness reference hole system
+/- 20 µm (0.8 Mil)
Minimal drill diameter
0.2 mm
