7 Trouble shooting
This chapter gives some information concerning correction of small faults that
may occur during operation of the circuit board plotter.
Please contact the LPKF service if the measures described in
this chapter do not provide the desired success. LPKF is not
liable for improper repairs!
Tab. 14: Trouble
shooting
Check the mains cable and insert the
mains plug into the socket if necessary.
Click Machining>Connect and the window
“Connect the machine” opens. Click
[Connect].
Main switch of the circuit
board plotter is in position
OFF
Set the switch to position ON.
Click Machining>Connect and the window
“Connect the machine” opens. Click
[Connect].
Check the USB cable between plotter and
PC. Fix the connector plug or exchange the
USB cable.
Click Machining>Connect and the window
“Connect the machine” opens. Click
[Connect].
Check the USB settings of the operating
system.
Click Machining>Connect and the window
“Connect the machine” opens. Click
[Connect].
Check the mains cable and insert the
mains plug into the socket if necessary.
Main switch of the dust
extraction is in position OFF
Set the operation mode switch to either ON
or AUTOMATIK.
Press the Reset Button of the dust
extraction.
Check the USB cable between circuit
board plotter and dust extraction. Fix the
connector plug or exchange the cable.
Position of the tool holder is
incorrect
Import the tool holder position again.
Tool was not correctly
inserted into the tool holder
Insert the tool with its top down into the tool
holder until it stops.
