8.2 Maintenance
For proper function of the circuit board plotter maintenance activities have to be
carried out in certain intervals.
ATTENTION
Risk of injury by unintended operations!
Any accidental starting of the motor and moving of the mill/drill
head during repairs or maintenance may cause severe injuries.
Make sure that only one person operates the machine. Secure
the machine during servicing and repair activities appropriate.
ATTENTION
Risk of injury by sudden cover closing!
The opened soundproof cover may close accidentally and jam
finger or the complete hand.
Always lift the soundproof cover up to the latching position and
secure the machine against any shocks.
Tab. 15:
Maintenance and
service plan
Component
Interval/Control
Maintenance activity
Milling depth limiter
After 100 operating
hours
cleaning
Chucks
After 100 operating
hours
cleaning
Tool position
Tool is not correctly
inserted
Configure tool position
Dust extraction
Extraction power
decreases perceptible
Exchange fine particle filter
