Functional description
ProtoMat S
36 HB V2.0/Dez-11 © 2011 LPKF AG
3
3.3 Conditions of use
The circuit board plotter can be used for production of single and multi-sided
circuit boards. Processing of signs as well as housing parts e.g. back or front
plates are acceptable likewise.
Permitted machining processes are:
●
Milling and drilling of single and double sided base material
●
Milling and drilling of multilayer material
●
Milling of SMD soldering paste stencils
●
Milling of solder resist mask
●
Engraving of signs or housing plates
●
Perforation of flat materials
●
Milling of cut-outs and outlines
●
Milling of 3D objects
●
Dispensing
The following materials are permitted for this circuit board plotter:
●
GFK or CFK base material
●
PTFE or ceramic-filled base material
●
Wood
●
Nonferrous materials as:
- Aluminium acc. to DIN EN 573:EN AW-6012
- Brass acc. to DIN EN 1412: CW603N
●
Plastics as:
- Polyoxymethylen
- ABS-Copolymere
The circuit board plotter may only be operated for the machining processes and
materials listed in this chapter.
The circuit board plotter may only be operated using the delivered control
software CircuitPro.
Note
Please contact the LPKF service at once if you wish to use an
other control software as the delivered item!
The circuit board plotter may only be start up with a sufficient dust extraction
and a fine particle filtering.
Memo
We recommend the LPKF dust extraction system with
integrated HEPA filter.
Note
Please contact the LPKF service first if you plan to use an
other dust extraction system.
