LPKF ProtoMat S - Tool Set 1;8

Appendix
ProtoMat S
102 HB V2.0/Dez-11 © 2011 LPKF AG
10
Tab. 16: Tools
Tool specification
Length
(mm)
Ø
(mm)
Order
code
Spiral Drill, cylindrical, 1/8“
38
1,50
115 860
Spiral Drill, cylindrical, 1/8“
38
1,60
115 861
Spiral Drill, cylindrical, 1/8“
38
1,70
115 862
Spiral Drill, cylindrical, 1/8“
38
1,80
115 863
Spiral Drill, cylindrical, 1/8“
38
1,90
115 864
Spiral Drill, cylindrical, 1/8“
38
2,00
115 865
Spiral Drill, cylindrical, 1/8“
38
2,10
115 866
Spiral Drill, cylindrical, 1/8“
38
2,20
115 867
Spiral Drill, cylindrical, 1/8“
38
2,30
115 868
Spiral Drill, cylindrical, 1/8“
38
2,40
115 869
Spiral Drill, cylindrical, 1/8“
38
2,95
115 870
Spiral Drill, cylindrical, 1/8“
38
3,00
115 871
Furthermore LPKF offers tool sets.
10.1.1.1 Tool set 1/8“
Order code: 129 103
Tab. 17: Tool set
1/8“
Tool specification
Length
(mm)
Ø
(mm)
Quan-
tity
End Mill, cylindrical, PCB/Aluminium, 1/8“
36
1,00
2
End Mill, cylindrical, PCB/Aluminium, 1/8“
36
2,00
1
Contour Router, special tool, cylindrical, 1/8“
38
1,00
1
Contour Router, special tool, cylindrical, 1/8“
38
2,00
1
Spiral Drill, cylindrical, 1/8“
38
0,60
5
Spiral Drill, cylindrical, 1/8“
38
0,70
5
Spiral Drill, cylindrical, 1/8“
38
0,80
5
Spiral Drill, cylindrical, 1/8“
38
1,00
5
Spiral Drill, cylindrical, 1/8“
38
1,10
2
Spiral Drill, cylindrical, 1/8“
38
1,20
2
Spiral Drill, cylindrical, 1/8“
38
1,50
2
Spiral Drill, cylindrical, 1/8“
38
3,00
2
