5.3.2 Commissioning
Always activate the system in the same sequence:
I.
Switch on the PC (control unit)
II.
Switch on the dust extraction and set the operation mode to automatic
or constant operation
III.
Switch on the circuit board plotter
■ System start up
1. Start the PC.
2. Switch on the dust extraction.
3. Turn the operation mode switch into the automatic position.
4. Adjust the desired extraction power.
5. Open the cover of the circuit board plotter.
6. Activate the circuit board plotter by setting the main switch to position I
(ON).
7. Close the cover.
8. Start CircuitPro.
➨ The CircuitPro start-up logo is displayed:
Fig. 21: Start-up
Logo
♦ The circuit board plotter is ready.
