© 2011 LPKF AG HB V2.0/Dez-11 49
12. Plug the other side of the tube on the coupler of the dust extraction.
For ProtoMat S103:
13. Plug the compressed air hose on the compressed air connection of the
machine (located on the back side, at the bottom of the left side).
14. Connect the other end of the hose with the central or local compressed
air supply.
♦ Now the circuit board plotter is connected.
Do not connect any UBB hub to the USB interfaces of the
machine. The USB interface does not support this configuration at
all.
