LPKF ProtoMat S - HF and Micro Wave Tool Set 1;8; Consumables; Base Material

ProtoMat S
Appendix
© 2011 LPKF AG HB V2.0/Dez-11 103
10
10.1.1.2 HF and micro wave tool set 1/8“
Order code: 116 394
Tab. 18: HF-Tool
set 1/8“
Tool specification
Length
(mm)
Ø
(mm)
Quan-
tity
End Mill RF, special tool, cylindrical, 1/8“
36
0,15
3
End Mill RF, special tool, cylindrical, 1/8“
36
0,25
5
End Mill RF, special tool, cylindrical, 1/8“
36
0,40
3
End Mill long, cylindrical, PCB/aluminium 1/8“
38
2,00
2
End Mill, cylindrical, PCB/aluminium, 1/8“
36
1,00
5
End Mill, cylindrical, PCB/aluminium, 1/8“
36
2,00
2
10.1.2 Consumables
10.1.2.1 Base material
Tab. 19: Base
material
Material
Dimensions
(mm)
Copper
(µm)
Quan-
tity
Order code
Base material FR4
420 x 297 x 1,5
18/18
10
106 398
Base material FR4
420 x 297 x 1,5
-/35
10
106 400
Base material FR4
420 x 297 x 1,5
35/35
10
106 401
Base material FR4
with protective foil
420 x 297 x 1,5
5/5
10
112 059
Base material FR4
reference holes 3 mm
229 x 305 x 1,5
18/18
10
115 967
Base material FR4
reference holes 3 mm
229 x 305 x 1,5
-/18
10
115 968
Base material FR4
reference holes 3 mm
229 x 305 x 1,5
-/35
10
115 969
Base material FR4
reference holes 3 mm
229 x 305 x 1,5
35/35
10
115 970
Base material FR4
reference holes 3 mm and
protective foil
229 x 305 x 1,5
5/5
10
115 971
