LPKF ProtoMat S - Worktable Protomat S63

ProtoMat S
Functional description
© 2011 LPKF AG HB V2.0/Dez-11 31
3
3.2.2.2 Worktable ProtoMat S63
Fig. 10:
Worktable
ProtoMat S43
/1/ Worktable
/2/ Power switch
/3/ Fixing pin
/4/ Tool magazine
/5/ Mill/Drill head
2
1
3
4
5
