3.2 Machine design
ProtoMat S series circuit board plotters are constructed equally in principle to
facilitate upgrades as simple as possible.
3.2.1 Housing
Fig. 4: Front view
/1/ Soundproof housing
/2/ Cover knob
/3/ Soundproof cover
1
2
3
