Functional description
ProtoMat S
28 HB V2.0/Dez-11 © 2011 LPKF AG
3
Fig. 5: Rear view
/1/ Compressed air connection for
vacuum table
/2/ Interfaces
/3/ Suction tube to connect the dust
extraction unit
Fig. 6: Interfaces
/1/ USB port
/2/ LPKF ports (4 x SUB-D, 25 pin.)
1
1
2
2
3
