LPKF ProtoMat S - Technical Data; Protomat S43

Functional description
ProtoMat S
38 HB V2.0/Dez-11 © 2011 LPKF AG
3
Pos: 11 /ED_Tec hnische_Doku mentation/2_Be dienungsanleit ung/Maschine/R P_Fräsbohrplotter/ ProtoMat _S_Serie/Prot oMat_S_Serie_IIG /Kapitel_3_Fu nktionsbeschreib ung/3_4_Tec hnische_Daten @ 1\mod_131 8346066315_2 058.docx @ 37604 @ 2333 @ 1
3.4 Technical Data
3.4.1 ProtoMat S43
Technical data circuit board plotter type ProtoMat S43:
Tab. 6: Technical
data ProtoMat
S43
Data
Values
Mains power supply
Voltage range from 110 to 240 V AC, 50 - 60 Hz
Power consumption
400/450 W
Weight
Appr. 58 kg
Dimension
670 x 540 x 760 mm (W x H x D)
Permissible ambient temperature
Range from 15 to 25 °C
Permissible atmospheric humidity
Up to 60 %
Workplace noise level
71 dB (A), devoid of noise level dust extraction
Motor mill/drill head
Three phase motor
Range of speeds
Up to 40,000 min
-1
(variable)
Processing speed
150 mm/s
Drilling capacity
150 strokes per minute
Tool change mechanism
Manually
Tool collet base
3.175 mm (1/8“)
Motor X-axis
Three phases stepping motor
Motor Y-axis
Three phases stepping motor
Motor Z-axis
Two phases stepping motor
Milling depth adjustment
Manually
Working area with work table
305 x 229 x 32.5 mm (X x Y x Z)
Working area with MKHP plate
305 x 229 x 26.5 mm (X x Y x Z)
Working area with vacuum table
305 x 229 x 17 mm (X x Y x Z)
Resolution (X/Y)
+/- 0.8 µm (0.04 Mil)
Repeat accuracy
+/- 5 µm (0.2 Mil)
Exactness reference hole system
+/- 20 µm (0.8 Mil)
Minimal drill diameter
0.2 mm
