LPKF ProtoMat S - Vacuum Table Protomat S103; Tool Magazine

Functional description
ProtoMat S
32 HB V2.0/Dez-11 © 2011 LPKF AG
3
3.2.2.3 Vacuum table ProtoMat S103
The vacuum table is optionally available for ProtoMat S63.
Fig. 11:
Worktable
ProtoMat S43
/1/ Vacuum table
/2/ Tool magazine
/3/ Power switch
/4/ Compressed air controller
/5/ Dispenser connection
/6/ Pressure display
3.2.2.4 Tool magazine
The work or vacuum table of machines with automatically tool change function
are equipped with a tool magazine.
Fig. 12: Tool
magazine
/1/ Tool number 1 … 15
/4/ Tool clamp 1 … 15
2
1
3
4
5
6
7
1
2
