363-206-285 System Turnup: NTP-028
Issue 2, February 2000 Page 2 of 6
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED . . . . .FOR DETAILS, GO TO
NOTE:
If the DDM-2000 fails to respond in the indicated manner,
refer to Trouble Clearing: IXL-001.
Verify that no LEDs or alarms are activated. If any LEDs or alarms
are activated, refer to Trouble Clearing: IXL-001 and follow the
appropriate trouble-clearing procedure.
2.
NOTE:
The rtrv-eqpt: command retrieves the Equipage and
Version Report. This report lists the circuit pack type
and version information for one or more slots. See the
Commands and Reports section of this manual for a
description of the rtrv-eqpt: command format.
At each DDM-2000 OC-3 terminating end, use the rtrv-eqpt:
command to obtain the Equipage and Version Report and
verify that the proper service and protection (if required) MXRVO
circuit packs have been installed in FUNCTION UNITS group(s)
(A, B,orC) being put into service.
3. At the LAN terminating nodes of the circuit being established,
determine from work order and office records which LAN port is to
be put into service and what options are to be selected.
DLP-5184. At each LAN terminating node, set power jumpers and install IMA
LAN circuit pack(s), as required.
5.
NOTE:
The BBF9 IMA LAN circuit pack has an RJ-45 connector on
the faceplate and requires Cat 5 cable for 100 mb
transmission or Cat 3 or higher for 10 mb transmission. The
BBF10 IMA LAN has an optical connector on the faceplate
for optical cable.
Install cable to connector on faceplate of IMA LAN circuit pack.
6. Upgrade all LAN nodes to latest IMA LAN software release, if
required.
DLP-525A. In-Service Local Software Download
DLP-528B. In-Service Remote Software Download
DLP-518
DLP-525
DLP-528
