363-206-285 Circuit Order: NTP-031
Issue 2, February 2000 Page 2 of 6
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED . . . . .FOR DETAILS, GO TO
3.
!
CAUTION:
No service
LOW SPEED
slots should be left empty .
DLP-518If a new IMA LAN circuit pack is being installed, remove 177A
Retainer Cards from LOW SPEED slots being equipped, then set
power jumpers and install new IMA LAN circuit pack.
4. At the LAN terminating node(s) of the circuit being established,
determine which LAN port(s) is to be put into service and what
options are to be selected.
5.
NOTE:
The BBF9 IMA LAN circuit pack has an RJ45 connector on
the faceplate and requires Cat 5 cable for 100 mb
transmission or Cat 3 or higher for 10 mb transmission. The
BBF10 IMA LAN has an optical connector on the faceplate
for optical cable.
Install cable to connector on faceplate of IMA LAN circuit pack
6. Upgrade all LAN nodes to latest IMA LAN software release, if
required.
DLP-525A. In-Service Local Software Download
DLP-528B. In-Service Remote Software Download
7. At each LAN terminating node, use the set-t1: and set-lan:
command to set the characteristics of the LAN port and protocols
of the circuit being established. See the Commands and Reports
section of Volume I of this manual for an explanation of these
commands.
8. At each LAN terminating node, make the appropriate cable
connection(s) to the DS1/DS3 cross-connect point(s) or
equivalent connection point(s) for the circuit(s) being added.
9. Verify that no LEDs or alarms are activated. If any LEDs or alarms
are activated, refer to Trouble Clearing: IXL-001 and follow the
appropriate trouble-clearing procedure.
DLP-518
DLP-525
DLP-528
