363-206-285 Detailed Level Procedure: DLP-562
Issue 2, February 2000 Page 5 of 12
DDM-2000 OC-3 MULTIPLEXER
8. Enter the command cpy-prog:tid or cpy-prog:tid,pgmtype=nesw.
Where tid = the target identifier (shelf name) for the remote
DDM-2000 shelf receiving the new program.
Where pgmtype = the type of software you want to install.
Response: /* Testing For Program Installation... */
After several seconds, the PC prints a Caution!
message followed by the prompt:
Execute? y/n =.
9. Was response correct?
If YES, then continue with Step 10.
If NO, then do Trouble Clearing: TAP-116.
10. Enter a y or yes and a carriage return to execute the program. Software
download may take up to 20 minutes.
Response: ABN LED lights on User Panel. A "P." is displayed in
SYSCTL FE ID display in the far-end shelf receiving the
program (for uncompressed executingcopy download, not
if dormant copy is being loaded). At DDM-2000 shelves
connected directly to the shelf receiving the program, MJ
and NE ACTY LEDs light on User Panel and FAULT LED
flashes on OHCTL. At other shelves in the same control
system, MJ and FE ACTY LEDs light on User Panel.
Download begins and the following message is displayed:
In progress....
The dots continue to print until program installation is
complete. After installation is completed, the PC prints the
following completion message:
ins-prog:TID COMPLD
/* Generic a.b.c is installed */
The LEDs go off on the User Panel and SYSCTL.
TAP-116
