3-128
12. Check that hydraulic oil temperature monitor (7) is displaying
the correct temperature.
• (A) Display when temperature is correct: Monitor background
(C) is blue.
• (B) Display when temperature is low: Monitor background (C)
is white.
If the hydraulic temperature monitor is not displaying the correct
temperature (it is displaying low temperature), repeat Steps 7 to
11 until the display is the correct temperature.
13. Check that engine coolant temperature monitor (1) displays the
correct temperature.
• (A) Display when temperature is correct: Monitor background
(C) is blue.
• (B) Display when temperature is low: Monitor background (C)
is white.
If it displays low temperature, carry out additional warm up of the
engine until engine coolant temperature monitor (1) displays the
correct temperature.
14. Check that the hydraulic oil temperature monitor and engine
coolant temperature monitor are displaying the correct
temperature, and then check that all the gauges and caution
monitors on the machine monitor are in the following status.
• Engine coolant temperature monitor (1): Displays correct
temperature
• Hydraulic oil temperature monitor (7): Displays correct
temperature
• Charge level monitor (8): OFF
• Engine oil pressure monitor (9): OFF
• Engine oil level monitor (10): OFF
• Engine pre-heating monitor (11): OFF
• Engine coolant temperature gauge (12): Indicator in green
range
• Hydraulic oil temperature gauge (13): Indicator in green range
• Fuel gauge (14): Indicator in green range
• Fuel level monitor (15): Displays appropriate level
15. Check for abnormal exhaust gas color, noise, or vibration. If any problem is found, contact us or our
sales service agency.
CAUTION
In cold temperature (ambient temperature below 0 degrees C), even when the hydraulic oil
temperature monitor displays the correct temperature, carry out additional Step 16 to warm up
all the hydraulic equipment.
