After placing the machine on the specified position of the trailer, secure it according to the following
procedure.
1. Operate blade control lever to lower the blade.
2. Set the lock lever securely to the LOCK position (L).
3. Stop the engine, and then remove the key from the starter
switch.
4. Close all doors, windows, and covers. Lock covers, caps, and
doors fitted with locks.
5. Place blocks under both ends of the tracks to prevent the
machine from moving during transportation, and secure the
machine with chains or wire ropes of suitable strength.
Be particularly careful to secure the machine in position so that it
does not slip to the side.
When securing the machine, put blocks between the wire rope
and the machine to prevent damage to the rope or machine.
[STOWING RADIO ANTENNA]
• Loosen bolt (2) of radio antenna (1) at the rear of the cab, lower
the antenna (1), then tighten bolt (2) again to secure radio
antenna (1) in position.
• When unloading the machine from the trailer and operating it,
follow the opposite procedure from stowing to set radio antenna
(1) vertical, then secure it in position with bolt (2).
