Maeda LC1385M-8BF - Specifications; Dimensions

6-42
10. SPECIFICATIONS
CAUTION
In this section, the data indicated is exclusive for the Fly-jib model but different from those of a
standard model.
For data other than this, refer to the section: “SPECIFICATIONS” of the LC1385 operation
manual.
System / Item
LC1385M-8BF
Mass and
dimensions
Machine mass
15,850kg
Overall length x width x height
6,545mm x 2,490mm x 2,965mm
Distance between idler and sprocket
2,880mm
Track gauge
1,990mm
Track width
500mm
11. DIMENSIONS
