• Before operating the travel lever or travel pedal, check the direction that the track frame is
facing. When the track frame is facing the rear (when the sprocket is at the front), the direction
of operation of the travel lever and travel pedal is the opposite to the direction of movement of
the machine (forward/reverse, left/right).
• Do not allow anyone to enter the area around the machine.
• Remove any obstacles from the travel path.
• Before starting the machine off, check that the area around the machine is safe, and sound the
horn.
• The area at the rear of the machine is a blind spot. Always use the rear view camera to check
the area at the rear of the machine before traveling in reverse.
• When the auto-deceleration is being used, if the travel lever or travel pedal are operated, the
engine speed will suddenly rise, so be careful when operating the travel lever or travel pedal.
• The accelerator pedal should only be used to control the crane operation while the machine is
stationed. During traveling operation, use of this pedal is strictly prohibited; otherwise it may
cause an accident due to an operation error which may lead to serious personal injury. During
traveling operation, always adjust the engine speed only by turning the fuel control dial.
• When traveling, check that the travel alarm sounds properly.
• During traveling, crane operation such as swinging or boom retraction is also available,
however, always avoid such operations. For a crane operation such as swingiing, always stop
traveling, beforehand.
[PREPARATIONS FOR MOVING THE MACHINE]
1. Press swing lock switch (1) to the ON (actuated) position and
confirm that swing lock monitor (2) lights up.
(a): ON position
(b): OFF position
2. Turn fuel control dial (3) towards the full speed (MAX) position to
increase the engine speed.
